Product: D81607-WHI, L 1200 mm x W 74 mm x H 71 mm, 3000°K — Datasheet ✓
Short description: Viisi- Suspension - Direct Light - 23W 3000K LED - Tri-mode dimming - White.

---

European Quality. Discounted prices. In-stock products to illuminate your space. Canada and the United States. Lighting experts available.
Accessible and affordable lighting fixtures that were recently in the Zaneen program. Massive savings. While quantities last!

---

General
Series: Viisi
Brand: Panzeri
Division: Design
Mounting Type: Suspension
Mounting Location: Ceiling
Subcategory: Pendant

---

Physical
Shape: Abstract
Length (mm): 1200
Length (in): 47 1/4
Width (mm): 74
Width (in): 2 15/16
Height (in): 2 13/16
Height (mm): 71
Max. Overall Height (mm): 2071
Max. Overall Height (in): 81 9/16
Light Distribution: Direct
Weight (kg): 1.45
Weight (lbs): 3.2
Diffuser: Opal, poly-carbonate
Fixture Material: Aluminum
Cable Details: Power supply: Transparent PVC 2300mm / 90 11/16" Suspension kit: steel wire 2000mm / 78 11/6"

---

Electrical
Input Wattage Range: 20 - 29 W
Lamp Type: LED
Input Wattage (W): 23.2
Total Output Wattage (W): 19.6
Dimming: Non-Dimmable / 0-10V Dimming
Driver Included: Yes
Driver Location: Integrated
Driver Type: Constant Current - Universal
Driver Class: Class 2
Input Voltage (V): 120 - 277
Output Voltage (V): 24

---

LED
Number of LEDs: 2 x 9.8
Color Temperature (°K): 3000
Max. Delivered Lumen (lm): 1502
Nominal Lumen (lm): 3275
CRI: >80 CRI
Efficiency (%): 45.863
Efficacy (lm/w): 65.3
Lamp Life (hrs): 50000

---

Optical
Optic°: Diffused

---

Ratings and Certifications
Certified By: CSA Certified to UL and CSA Standards
IP rating: IP40
